How to use or fill out the COPPER-FIN START-UP CHECKLIST - Lochinvar :: High Efficiency online
The COPPER-FIN START-UP CHECKLIST is an essential tool for ensuring that Lochinvar high efficiency products are installed and operating correctly. This guide provides clear, step-by-step instructions to help users fill out the checklist accurately online.
Follow the steps to complete the checklist efficiently.
- Press the ‘Get Form’ button to obtain the checklist and open it in your online editor.
- Begin filling out the form by entering the job name and model number in the designated fields. Next, provide the installation address, including the city and zip code.
- Indicate whether the installation is a retrofit or a new project and specify the number of boiler and water heater units installed at the location.
- Inspect the gas pipe, regulator, and meter sizing to confirm it meets the Btu/Hr requirement, marking 'yes' or 'no' as appropriate.
- Document the inlet and outlet temperatures, delta T, supply voltage, and total amp draw under the water & electrical section.
- Record the gas supply information, including gas pipe diameter, total equivalent length, and whether there is an inlet gas lockup regulator with the specified upstream distance.
- Enter the gas pressure readings for all valves and record relevant water temperatures like high limit, static pressure, and differential pressure readings as outlined.
- Select the appropriate venting option and provide details about combustion and ventilation openings, as well as any required comments or corrections.
- Measure and record service clearances from the nearest obstruction for front, left side, rear, right side, and top.
- Complete the technician information section with the startup performed by details and general job notes.
- Finally, review your entries for accuracy before saving or printing the completed checklist. If necessary, use the submit option to send the form digitally.
Complete your COPPER-FIN START-UP CHECKLIST online today for efficient and reliable documentation.
EFFECTIVE: For 15 Years Lochinvar warrants the heat exchanger and/or tank against failure due to defects in materials or workmanship. For the lifetime of the product, Lochinvar warrants the tank and/or heat exchanger against failure due to thermal shock.
