This guide provides clear and detailed instructions on how to fill out the 5. E-axis Assembly (spiral wrap) by Prusa3D. It is designed to support users through the assembly process with ease and confidence.

Follow the steps to successfully complete the E-axis assembly.

1. Press the ‘Get Form’ button to access the document and open it for editing.
2. Identify the type of sleeve you have: Ensure you have the spiral wrap before proceeding with this chapter. If you have a textile sleeve, refer to the correct chapter instead.
3. Prepare the necessary tools for assembly, including needle-nose pliers, various sizes of Allen keys, and screws for assembly.
4. Begin the idler assembly by gathering required parts such as the extruder-idler, Bondtech pulley, bearing, and nuts.
5. Carefully assemble the idler by securing bearings and inserting them correctly into the pulley.
6. When assembling filament sensors, take care to properly slot nuts into the extruder body to avoid later accessibility issues.
7. Follow each detailed instruction for the assembly of components like the extruder motor, the cooling fan, and the wiring, ensuring proper orientation and tightening.
8. Complete the assembly by ensuring all wires and parts are neatly arranged, tightening screws as necessary while checking for proper alignment.
9. Finalize the assembly of the spiral wrap around cables as per instructions. Tighten with zip ties and ensure everything is secure.
10. After completing the assembly, review your work against the final images provided within the document, then move on to the subsequent assembly stages.
