This guide provides clear, step-by-step instructions on completing the 3AH5 vacuum circuit-breaker order form online. Whether you are experienced or new to the process, this resource aims to support you in navigating the necessary fields effectively.

Follow the steps to complete the 3AH5 form.

1. Click ‘Get Form’ button to obtain the form and open it in the editor.
2. Fill in your personal information, including your name and contact details, ensuring accuracy for future communication.
3. Select the rated voltage from the given options (e.g., 12 kV, 17.5 kV, 24 kV, 36 kV) as required for your application.
4. Specify the required rated lightning impulse withstand voltage for your circuit-breaker.
5. Indicate the short-duration power-frequency withstand voltage needed for your application.
6. Fill in the rated short-circuit breaking current required, selecting from the available options.
7. Choose the rated normal current according to your specifications.
8. Define the pole-centre distance required for installation.
9. Select the options for secondary equipment and specify the desired release combination.
10. Review your entries for accuracy before submitting the form.
11. After completion, you can save changes, download, print, or share the form as necessary.

Start filling out your 3AH5 form online today for efficient configuration and order placement.
