Charpy Impact Test If the hammer swings to a high angle after fracturing the test piece, this indicates that the test piece failed to absorb the impact. If the hammer swings to a low angle, this indicates that the test piece absorbed more of the impact.

The impact strength (resilience) is calculated directly by dividing the impact value obtained from the measure by the thickness of the specimen (dimension J/m) or by the residual area under the notch (dimension kJ/m2).

The standard Charpy Impact Test specimen consist of a bar of metal, or other material, 55x10x10mm having a notch machined across one of the larger dimensions. The Charpy Impact Test consist of striking a suitable specimen with a hammer on a pendulum arm while the specimen is held securely at each end.

Note Energy: Most Charpy testing machines will have a dial graded in joules. The energy absorbed must be divided by the cross-sectional area of the sample at the V-notch to calculate the impact strength. The unit of impact strength is J/m2.

Impact tests to Charpy are also described in the ASTM D6110 standard. Impact tests ing to the Charpy method are used for the characterization of a plastic material at high strain rates. The abrupt load is applied in a 3-point flexure fixture.

Charpy Impact Test The impact value is derived from the energy at the time the test piece fractured, and is used to evaluate the toughness and brittleness of the test piece material.

IZOD Impact Strength Test A pivoting arm is raised to a specific height (constant potential energy) and then released. The arm swings down hitting a notched sample, breaking the specimen. The energy absorbed by the sample is calculated from the height the arm swings to after hitting the sample.

We can use the pulse width and employ Newton's 2nd law of motion, F=ma to calculate the expected impact force. Using the final velocity calculated from the conversation of energy Equation 1, v = √2gh, we may compute the resulting impact acceleration.
