Get Z101-86 Specification Sheet 20 508 Diameter Combination - Zurn Eriepa

Filling out the Z101-86 specification sheet is an essential step in documenting your requirements for the Zurn Eriepa roof drain. This guide will provide you with clear, step-by-step instructions to ensure the form is completed accurately and efficiently.

Follow the steps to complete your specification sheet online.

1. Press the ‘Get Form’ button to access the document and open it in the editing tool.
2. Begin by filling in the 'TAG' section with a relevant identifier for your project, ensuring it is easy to reference.
3. Locate the dimensional data section; select the appropriate pipe size from the options provided (3, 4, or 6 inches).
4. For the selected pipe size, enter the approximate weight in pounds and kilograms in the designated field.
5. Indicate the dome open area by entering the corresponding square inches in the specified section.
6. In the 'PREFIXES' and 'SUFFIXES' sections, fill in any applicable information. You may select from options like ‘Z’ for prefixes or suffixes such as ‘-AR’, ‘-DP’, ‘-G’, and ‘-EB’.
7. Provide the engineering specification by confirming the main attributes, including the body material and any special conditions such as 'no-hub' configuration.
8. In the 'OUTLET' section, ensure that you specify the type of outlet required for the installation.
9. Complete the 'E BODY HT. DIM.' by entering the height dimension as provided in the specification.
10. Finally, review all entries for accuracy, make necessary adjustments, and then save changes. You can download, print, or share the completed form as needed.

Complete your Z101-86 specification sheet online for effective project documentation.
