Get A1005-505c Stainless Steel Retrofit Data Sheet

Filling out the A1005-505C Stainless Steel Retrofit Data Sheet online is a straightforward process that ensures your information is accurately captured. This guide will walk you through each step to complete the form efficiently and effectively.

Follow the steps to fill out the form successfully.

1. Click ‘Get Form’ button to obtain the form and open it in the editor.
2. Begin by entering the smallest inside diameter of the manhole in field A.
3. Next, record the outside lip diameter of the drain channel in field B.
4. Enter the inside diameter of the rim in field C.
5. Fill in the outside diameter of the rim in field D.
6. Provide the depth from the top of the drain channel to the bottom of the manhole in field E.
7. In field F, indicate the number of protrusions on the rim.
8. Complete fields G1 through G4 with the inside measurements of the manhole containment wall.
9. Measure the depth from the top of the drain channel to the top of the riser in field H.
10. Indicate the model number in the designated field for the manufacturer (EBW, Emco, OPW, etc.).
11. Answer whether there is an existing drain by checking Yes or No.
12. Specify if a drain is required in the stainless steel liner by selecting Yes or No.
13. Clarify if the existing bucket is slip-on or thread-on.
14. Fill in the contact name and contact phone number to provide your information.
15. Attach required photos, including a top view with the lid, a top view without the lid, and any unique features.
16. Provide site location and tank ID if applicable.
17. Include any additional comments you may have regarding the retrofit.
18. Once all fields are complete, review your entries for accuracy and save your changes. You can then download, print, or share the form.

Start filling out your A1005-505C Stainless Steel Retrofit Data Sheet online today!
